OMT 5ton Direct Cooling Type Ice Block Machine
OMT 5ton Direct Cooling Type Ice Block Machine
OMT direct evaporating ice block machine has adopted the latest technology in the market, the evaporate is made by special design aluminum plate and assemble by welding format to make it more strong. The refrigerant is evaporating inside the evaporator, very efficiency and stable.
OMT 5ton Direct Cooling Type Ice Block Machine Testing
5ton Direct Cooling Type Ice Block Machine Parameter:
|
Item |
Parameters |
|
Model |
DOTB50 |
|
Ice Capacity |
?5,000kg/24hrs |
|
Ice Blcok Size ???? |
20kg(5kg, 10kg, 25kg, 50kg etc for option)?????? |
|
Ice Mold Size(Dimension): |
250*140*740 MM |
|
Ice Produced Quantity per batch |
91pcs |
|
Ice Freezing Time |
8hrs |
|
Ice Produced Quantity per 24hrs |
273pcs |
|
Ice Cans Material |
aluminum plate |
|
Cooling Way |
Water?cooled condenser |
|
Gas/Refrigerant |
R22/R404a for option |
|
Compressor power |
28HP, Refcomp/Bitzer |
|
Voltage |
380V,50Hz, 3 phase/380V,60Hz, 3 phase |
Machine Features:
High Quality Material
Ice?molds?are?made?of?aluminum?plate,?mainframe?adopts?anti-rust?and?anti-corrosion?material--stainless?steel.
Fast freezing?time but lower power consumption
Aluminum evaporator is of 3 times higher heat exchange efficiency than other steel like SUS304, galvanized steel, so ice block can be completely frozen faster. In this way, it can produce more ice blocks with lower power consumption.
Clean and edible ice block making
Evaporated?directly?without?using?chemical?and?salt?water, the?ice?is?clean?and?can?be?eaten?directly.
OMT 5ton Direct Cooling Type Ice Block Machine Pictures:
Front View
Side View
Main application:
Used in restaurants, bars, hotels, nightclubs, hospitals, schools, laboratories, research institutes and other occasions as well as supermarket food preservation, fishing refrigeration, medical applications, chemical, food processing, slaughtering and freezing industries.
